The EMBRACO UNEU2170UA condensing unit is designed for refrigeration systems operating in the LBP range with R290 refrigerant. The unit operates at 220–240 V and 50 Hz. The assembly includes a UNEU2155U compressor with a CSR motor.
The unit discharge is 16.80 mm and the COP is 1.24 W/W. The refrigeration circuit connections are brazed, with a 3/8" suction connection and a 1/4" discharge connection. The unit is designed for use with a capillary tube or valve.
The unit is equipped with a 254 mm diameter fan and a refrigerant receiver with a volume of 0.33 l. The dimensions of the condensing unit are 340 × 465 × 308 mm in width × length × height order. The unit weighs 20 kg.
For product identification, BOM code 565EAE409AA is specified. Before ordering, we recommend comparing the unit designation, compressor designation and individual technical parameters with the requirements of the specific refrigeration system.
Key Benefits:
- Designed for LBP applications
- For use with R290 refrigerant
- UNEU2155U compressor
- COP 1.24 W/W
- Brazed suction connection 3/8" and discharge connection 1/4"
- For use with a capillary tube or valve
- Fan diameter 254 mm
- Refrigerant receiver volume 0.33 l
Technical Specifications:
| Parameter | Value |
| Brand | EMBRACO |
| Designation | UNEU2170UA |
| Unit model | UNEU2170Ua |
| BOM code | 565EAE409AA |
| Product type | condensing unit |
| Application | LBP |
| Refrigerant | R290 |
| Voltage | 220–240 V |
| Frequency | 50 Hz |
| Discharge | 16.80 mm |
| Compressor | UNEU2155U |
| Motor type | CSR |
| COP | 1.24 W/W |
| Connection | brazed |
| Suction | 3/8" |
| Discharge connection | 1/4" |
| Control | capillary tube / valve |
| Fan diameter | 254 mm |
| Refrigerant receiver | 0.33 l |
| Dimensions W × L × H | 340 × 465 × 308 mm |
| Weight | 20 kg |
