Popis
HGX46/440-4 ML CO2 T, 097B16217, kompresor polohemetický BOCK, HGX46/440-4 ML CO2 T, napájení: 380 - 420 V / 50 Hz, maximální tlak: vysokotlaká strana: 150 [bar] / nízkotlaká strana: 100 [bar], ochrana motoru: INT69 G - 115-230 [V] AC 50/60 [Hz], typ oleje: BOCKlub E85, hmotnost: 242 [kg]
| Brutto hmotnost | 263.8 Kilogram |
| Čistá hmotnost | 242 Kilogram |
| Volume | 428.8 Liter |
| EAN | 5715162569610 |
| Anti-vibration pads | No |
| Barva | Blue (standard) |
| Capacity regulator | No |
| Celková výška [mm] | 403 mm |
| Chladivo (Chladiva) | R744 |
| Discharge connection comments | Standard |
| Discharge connection comments | Blind flange |
| Discharge connection comments | Standard |
| Discharge connection comments | Blind flange |
| Frequency [Hz] | 50 |
| Fáze | 3 |
| Hot gas temperature sensor | No |
| In scope of WEEE and contain batteries | No |
| Intermediate flange/adapter | No |
| Kompresor - zdroj napájení [V] | 380-420V Y/YY -3- 50Hz PW |
| Legacy BOCK ID | 16217 |
| Length (mm) | 774 |
| Max pressure (PS) - high side | 150 bar |
| Max pressure (PS) - low side | 100 bar |
| Model number | HGX46/440-4 ML CO2 T |
| Ochrana motoru | INT69 G 115-230V AC, 50/60 Hz, IP00 |
| Oil differential pressure sensor | No |
| Oil level regulator | No |
| Oil sump heater | 220-240V AC (V2A) |
| Oil temperature sensor | No |
| Označení typu | HGX46/440-4 ML CO2 T |
| Product Name Description | Reciprocating compressor HG |
| Produktová skupina | Semi-hermetic compressors |
| Schvalovací norma | No |
| Screw-in valve | No |
| Skupina | HG CO2 T Compressors |
| Technologie | Semi-hermetic CO2 transcritical |
| Thermal protection thermostat | No |
| Typ | HGX46 |
| Typ oleje | BOCKlub E85 |
| Třída IP | IP 66 |
| Výlec | 6 |
| Značení | BOCK |
| Šířka [mm] | 471 mm |
