VALUE VRR24M-C Refrigerant Recovery Unit

The VALUE VRR24M-C refrigerant recovery unit is designed for recovering refrigerants from air conditioning and refrigeration systems. It is used to remove refrigerant during service work, repairs, or equipment maintenance.

The VRR24M-C model is equipped with a 1 HP brushless motor and an oil-free, air-cooled piston compressor. According to the supplied manual, the unit features an electronic control panel, high-pressure protection, O.F.P. tank overfill protection, and operating modes for recovery, self-cleaning, and push/pull mode.

The unit is suitable for Category III, IV, and V refrigerants, including R134a, R22, R410A, and R32. The recovery rate varies depending on the refrigerant category and the operating method — vapor, liquid, or push/pull mode. During use, it is necessary to follow the correct service procedure and use suitable hoses, a filter drier, and a refrigerant recovery cylinder.

Main advantages:

• VALUE refrigerant recovery unit
• VRR24M-C model
• 1 HP brushless motor
• Suitable for Category III, IV, and V refrigerants
• Supports R134a, R22, R410A, R32, and other refrigerants
• Modes for vapor recovery, liquid recovery, and push/pull
• Electronic control panel according to the manual
• High-pressure protection
• O.F.P. tank overfill protection
• Compact design with a weight of 11.5 kg

Technical parameters:
Order code: 9013-27
Model: VRR24M-C
Product type: gas / refrigerant recovery unit
Brand: VALUE
Application: refrigerant recovery from air conditioning and refrigeration systems
Power supply: 220–240 V / 50–60 Hz
Motor: 1 HP, brushless motor
Motor speed: 3000 rpm
Operating temperature: 0 to +40 °C
Dimensions: 370 × 250 × 300 mm
Weight: 11.5 kg
Compressor: oil-free, air-cooled, piston type
Automatic safety shut-off / high-pressure protection: 38.5 bar / 3850 kPa / 558 psi

Suitable for refrigerants:
Category III: R12, R401C, R134a, R406A, R500, R1234yf
Category IV: R22, R401A, R401B, R402B, R407C, R407D, R408A, R409A, R502, R509
Category V: R402A, R404A, R407A, R407B, R410A, R507, R32

Recovery rate:
Category III:

• vapor: according to the chart in the manual
• liquid: 2.6 kg/min
• push/pull: 7.5 kg/min

Category IV:

• vapor: according to the chart in the manual
• liquid: 2.9 kg/min
• push/pull: 8.5 kg/min

Category V:

• vapor: according to the chart in the manual
• liquid: 3.9 kg/min
• push/pull: 9.5 kg/min
