The VALUE VRR12LOS-R32 refrigerant recovery unit is designed for recovering refrigerants from air conditioning and refrigeration systems. It is used during service work, repairs, or maintenance of equipment where it is necessary to remove refrigerant from the system into a recovery cylinder.
The VRR12LOS-R32 model is equipped with an oil separator, a 3/4 HP motor, and operates at 1450/1750 rpm. According to the provided data, the unit is suitable for Category III, IV, and V refrigerants, including R1234yf, R410A, and R32.
The device allows refrigerant recovery in vapor, liquid, and push/pull modes. The recovery rate varies depending on the refrigerant category and operating mode. The unit measures 450 × 250 × 355 mm and weighs 14.2 kg.
Main advantages:
- VALUE unit for refrigerant recovery
- VRR12LOS-R32 model according to the provided data
- Oil separator
- 3/4 HP motor
- Suitable for Category III, IV, and V refrigerants
- Supports R1234yf, R410A, R32, and other refrigerants
- Modes for vapor, liquid, and push/pull recovery
- Operating temperature 0 to +40 °C
- Suitable for servicing air conditioning and refrigeration systems
Technical specifications:
Order code: 9013-24
Model: VRR12LOS-R32
Product type: gas / refrigerant recovery unit
Brand: VALUE
Application: recovery of refrigerants from air conditioning and refrigeration systems
Design: with oil separator
Power supply: 220–240 V / 50–60 Hz
Motor: 3/4 HP
Motor speed: 1450/1750 rpm
Operating temperature: 0 to +40 °C
Dimensions: 450 × 250 × 355 mm
Weight: 14.2 kg
Suitable refrigerants:
Category III: R12, R134a, R401C, R500, R1234yf
Category IV: R22, R401A, R401B, R402B, R407C, R407D, R408A, R409A, R411A, R411B, R412A, R502, R509
Category V: R402A, R404A, R407A, R407B, R410A, R507, R32
Recovery rate:
Category III:
- vapor: 0.20 kg/min
- liquid: 1.6 kg/min
- push/pull: 4.6 kg/min
Category IV:
- vapor: 0.25 kg/min
- liquid: 1.8 kg/min
- push/pull: 5.6 kg/min
Category V:
- vapor: 0.25 kg/min
- liquid: 2.2 kg/min
- push/pull: 6.3 kg/min
