VALUE VRDDF Refrigerant Recovery Unit for A2L, A2, A3, R600a, and R1234yf

The VALUE VRDDF refrigerant recovery unit is designed for recovering refrigerants from refrigeration and air conditioning systems. According to the manufacturer, it is designed for use with flammable refrigerants and for refrigerants in classes A2L, A2, and A3. The supplied documentation lists, among others, refrigerants R1234yf, R600, R290, and R32.

The unit operates with an oil-free, air-cooled reciprocating compressor and offers three recovery modes: automatic, semi-automatic, and manual. The electronic design with a digital display facilitates reading operating parameters and, according to the documentation, is more accurate than a mechanical unit.

Main features include fast refrigerant recovery, a 1 HP brushless DC motor, a digital display with high-pressure and low-pressure gauges, an automatic self-cleaning function, one-button control, and a 2-cylinder compressor. The package includes a shoulder strap, a filter drier, a 15 cm 1/4" × 1/4" hose, and an O.F.P. hose.
Main advantages:

• VALUE VRDDF refrigerant recovery unit
• Designed for A2L, A2, and A3 refrigerants according to the documentation
• Suitable, among others, for R600a, R1234yf, R32, and R290
• Three recovery modes: automatic, semi-automatic, and manual
• Digital display with high-pressure and low-pressure gauges
• Automatic self-cleaning function
• 2-cylinder oil-free compressor
• ATEX certification and Ex marking according to the supplied documentation
• The package includes a shoulder strap, a filter drier, and hoses

Technical parameters:
Model: VRDDF
Product type: refrigerant recovery unit
Designed for refrigerants: A2L, A2, A3
Selected refrigerants according to the specification: R600a, R1234yf
Category III: R12, R134a, R401c, R500, R1234yf, R600
Category IV: R22, R401a, R401b, R402b, R407c, R407d, R408a, R409a, R411a, R411b, R412a, R502, R509, R290
Category V: R402a, R404a, R407a, R407b, R410a, R507, R32, R507
Power supply: 230/50 V/Hz
Motor power: 1 HP
Motor speed: 3000 rpm
Maximum current: 5 A
Compressor: reciprocating, air-cooled, oil-free
Automatic safety shut-off: 38.5 bar / 3850 kPa / 558 psi
Recovery rate, Category III – vapor / liquid / push-pull: 0.43 / 3.6 / 7.50 kg/min
Recovery rate, Category IV – vapor / liquid / push-pull: 0.54 / 4.0 / 8.50 kg/min
Recovery rate, Category V – vapor / liquid / push-pull: 0.54 / 4.2 / 9.50 kg/min
Operating temperature: 0 to 40 °C
Dimensions: 370 × 250 × 297 mm
Weight: 11.0 kg
Recovery modes: automatic, semi-automatic, manual
Display: digital
Certification / marking: ATEX, Ex
ATEX marking: II 3G Ex ec ic nC h IIA T4 Gc
Certificate number: CSANe 22ATEX 1032X
Package contents: shoulder strap, filter drier, 15 cm 1/4" × 1/4" hose, O.F.P. hose
Application: recovery of refrigerants from refrigeration and air conditioning systems
