VALUE VTB-5B-I Tool Set with R410A Manifold, 7023-16

The VALUE 7023-16 VTB-5B-I tool set is intended for service and installation work in refrigeration and air conditioning technology. It includes tools for tube work as well as a 2-way manifold gauge set for system service connection.

The set includes the VFT-808-I flaring tool, VTC-28B and VTC-19 tube cutters, the VMG-2-R410A 2-way manifold, the VTT-5 deburrer, and a case. It is therefore a practical set for tube preparation, cutting, deburring, flaring, and service work with R410A refrigerant.

According to the supplied data, the VMG-2-R410A manifold features gauges with a diameter of 80 mm, 3×150 cm hoses, and 1/4" SAE hose connections. The VFT-808-I flaring tool is intended for 1/4", 5/16", 3/8", 1/2", 5/8", and 3/4" tubes. The VTC-28B cutter is intended for 1/8" to 1.1/8" / 4–28 mm tubes, and the VTC-19 cutter for 1/8" to 3/4" / 3–19 mm tubes.

Main advantages:

• Complete VALUE tool set for the service and installation of air conditioners and refrigeration systems
• VMG-2-R410A 2-way manifold for R410A
• VFT-808-I flaring tool for imperial tube sizes
• Two tube cutters: VTC-28B and VTC-19
• VTT-5 deburrer for finishing tube edges
• 3×150 cm hoses according to the supplied data
• Supplied in a case as shown in the packaging photo

Technical parameters:
Order code: 7023-16
Set model: VTB-5B-I
Product type: tool set for refrigeration and air conditioning technology
Brand: VALUE
Application: service and installation of refrigeration and air conditioning systems

Set contents according to the packaging:

• Tube flaring tool: VFT-808-I
• Tube cutter: VTC-28B
• Tube cutter: VTC-19
• 2-way manifold: VMG-2-R410A
• Deburrer: VTT-5
• Packaging: Case

Manifold parameters according to the specification:
Refrigerant: R410A
Gauge diameter: 80 mm
Hose connections: 1/4" SAE
Hoses: 3×150 cm

VFT-808-I flaring tool parameters:
For tubes: 1/4", 5/16", 3/8", 1/2", 5/8", 3/4"

Tube cutter parameters:
VTC-28B: for 1/8" to 1.1/8" / 4–28 mm tubes
VTC-19: for 1/8" to 3/4" / 3–19 mm tubes

Additional tool:
Deburrer: VTT-5
