ENcondensing unit Tecumseh FHT4518YHR-XG, HBP- R134A, 380-400 V
motor type: 3 phase, cooling capacity: R134a 2248 [W], R513A 2405 [W] in +32 / -10 [°C] according EN13215, solder connection: suction: 5/8", discharge 3/8"
You need to be logged in to view information
| Order code 1: | 32 FHT4518YHR-XG |
| Order code 2: | FHT4518YHR-XG |
| VAT: | 0% |
| Unit: | pcs |
| Značka: | TECUMSEH |
Description
FHT4518YHR-XG, condensing unit Tecumseh FHT4518YHR-XG, HBP – R134a / R513A, 380-460V, 3 phase, 50/60 Hz, motor type: 3 phase, cooling capacity: R134a 2248 [W], R513A 2405 [W] in +32 / -10 [°C] according EN13215, solder connection: suction: 5/8", discharge 3/8", fan: 1335/1500 [rpm], fan power 90 [W], fan blade diameter 350 [mm], receiver: 1,5 [l] / 32 [bar], sound level 73 [dBA], expansion device: expansion valve, weight: 49,0 [kg], dimension (l x w x h): 512 x 607 x 436 [mm]replacement for: TFHT4518YHR
Technical specification
Condensing units
| Application |
Application
HBP |
| Model |
Model
condensing unit |
| Refrigerant |
Refrigerant
R134a; R513A |
| Type of compressor |
Type of compressor
hermetic - piston |
| Power supply |
Power supply
380 - 420V |
| Frequency |
Frequency
50 / 60 Hz |
| Brand |
Brand
Tecumseh |
| Cooling capacity regulation |
Cooling capacity regulation
ON/OFF |
