ENcompressor Copeland Scroll ZR94KCE-TFD 550, R22, R407C, 380 - 420 V
ZR94KCE-TFD455, compressor Copeland ZR94K3E-TFD455, R407C, R22, displacement 22,1 [m3/h], connecting: suction: 1 1/8", discharge:
You need to be logged in to view information
| Order code 1: | 32 ZR94 |
| Order code 2: | ZR94 |
| VAT: | 0% |
| Unit: | pcs |
| Značka: | COPELAND - série ZR |
Description
ZR94KCE-TFD455,ZR94-KCE-TFD550, compressor Copeland ZR94K3E-TFD455, R407C, R22, displacement 22,1 [m3/h], connecting: suction: 1 1/8", discharge: 7/8", oil quantity 2,65 [l], length x width x heigth: 264x285x476 [mm], sound pressure: 63 dBA @ 1 [m], recommended crankcase heater: 90 [W], net weight: 57,2 [kg]
Technical specification
Compressors
| Type of compressor |
Type of compressor
hermetic - scroll |
| Refrigerant |
Refrigerant
R134a; R22; R407C |
| Application |
Application
MBP; HBP; AC |
| Power supply |
Power supply
380 - 420V |
| Frequency |
Frequency
50 Hz |
| Motor type |
Motor type
TFD |
| Brand |
Brand
Copeland |
Ratings
discharge thermostat COPELAND, for serie: ZR, 8557419
You need to be logged in to view information
mounting kit H33 Copeland, ZR94-ZR190
You need to be logged in to view information
rubber grommet of compressors Copeland ZR 94 - 190, ZP 90 - 182
You need to be logged in to view information
