ENcompressor Copeland Scroll ZF09K4E-TFD 551, R22, R404A, 380-420V
ZF09K4E-TFd551, compressor Copeland ZF09K4E-TFd551, lBp - R404A, R22, displacement 8,0 [m3/h], rotalock suction: 1 3/4":, rotalock
You need to be logged in to view information
| Order code 1: | 32 ZF09 |
| Order code 2: | ZF09 |
| VAT: | 0% |
| Unit: | pcs |
| Značka: | COPELAND - série ZF |
Description
ZF09K4E-TFd551, compressor Copeland ZF09K4E-TFd551, lBp - R404A, R22, displacement 8,0 [m3/h], rotalock suction: 1 3/4":, rotalock discharge: 1", oil quantity: 1,50 [l], length / width / heigth: 243x244x392 [mm], sound pressure: 62 dBA @ 1 [m], recommended crankcase heater: 70 [W], net weight: 27 [kg]
Technical specification
Compressors
| Type of compressor |
Type of compressor
hermetic - scroll |
| Refrigerant |
Refrigerant
R404A; R22 |
| Application |
Application
LBP |
| Power supply |
Power supply
380 - 420V |
| Frequency |
Frequency
50 Hz |
| Motor type |
Motor type
TFD |
| Brand |
Brand
Copeland |
