MSH-240TB-3-9, heat pumps - DHW heater; MSH-240TB-3/9; 14,2 kW, R32
Internet control via ILetComfort app
High efficiency
Circulation pump with self-adjusting speed control
Integrated expansion tank and safety valve
Equitherm control, room temperature reference control or thermostat control
Quiet mode
Three-way valve included in the indoor unit
Built-in 3 or 9 kW electric cartridge
Power supply - 380 - 415 / 3 / 50 V / Ph / Hz
Piping - Gas Diameter 5/8/16 inch/mm
Piping - liquid Diameter 3/8 / 9.5 inch / mm
Piping inlet/outlet Diameter 1 mm (inch)
Safety valve - 3 Bar
Outlet Water Temperature Cooling 5-25 °C
Heating outlet water temperature 25-65 °C
Circulation pump Type Inverter -
Circulator Speed Automatic -
Circulation pump Max. power 90 W
Hot water tank Capacity 240 l
Hot water tank Electric heater 1.5 + 1.5 kW
Expansion tank Volume 8 l
Expansion tank Water pressure (Max) 3 Bar
Expansion vessel Air pressure (pre-pressurised) 1 Bar
Ele. heater Operation Automatic -
Ele. heater Power 9 kW
Ele. heater Combination 3 + 3 + 3 -
Ele. heater Power supply 380 - 415 / 3 / 50 V / Ph / Hz
Heat exchanger Type Plate -
Heat exchanger Quantity 1 -
Sound pressure level at 1 m - 29 dB(A)
External dimensions (W x H x D) 600 × 600 × 1943 mm
Package dimensions (W x H x D) 730 × 730 × 2180 mm
Net weight - 157 kg
Gross weight - 178 kg
