heat pump SHP-140ICA, R407c, 14,2 kW, S-THERM, indoor unit

SHP-140ICA; heat pump SHP-140ICA

power supply: 400V/3/50Hz, A 10°C/W 35°C - heating power: 15.29 [kW], power consumption: 3.16 [kW], COP: 4.84
A 7°C/W 35°C - heating power: 14.18 [kW], power consumption: 3.10 [kW], COP: 4.57
A 2°C/W 35°C: heating output: 8.79 [kW], power consumption: 3.10 [kW], COP: 3.83
A -7°C/W 35°C: heating output: 10.11 [kW], power consumption: 3.01 [kW], COP: 3.36
A -15°C/W 45°C: heating output: 9.03 [kW], power consumption: 3.98 [kW], COP: 2.27
pipe - liquid: 1/2" (12 mm)
pipe - gas: 3/4" (20 mm)
dimensions (w x h x d): 597 x 596 x 991 [mm]
weight: 150 [kg]
Specially designed EVI compressor for high water temperatures
Improved base frame reduces noise and vibration
WILO water pump
Reliable compressor COPELAND for refrigerant R407c
Huba Control flow sensor
The metal frame and chassis is made of galvanized steel with powder coating
Intelligent control and adjustment by microprocessor
LCD display with JOG control
3kW electric heater inside indoor unit
Measurement of current COP
Heated water temperature up to 60°C
5 year warranty
The product is registered in the New green savings program (SVT25122) and in Kotlík subsidies

A 10°C / W 35°C Heating power 15.29 kW
A 10°C / W 35°C Power consumption 3.16 kW
A 10°C / W 35°C COP 4.84 -
A 7°C / W 35°C Heating power 14.18 kW
A 7°C / W 35°C Power consumption 3.10 kW
A 7°C / W 35°C COP 4.57 -
A 2°C / W 35°C Heating power 8.79 kW
A 2°C / W 35°C Power consumption 2.30 kW
A 2°C / W 35°C COP 3.83 -
A -7°C / W 35°C Heating power 10.11 kW
A -7°C / W 35°C Power consumption 3.01 kW
A -7°C / W 35°C COP 3.36 -
A -15°C / W 45°C Heating power 9.03 kW
A -15°C / W 45°C Power consumption 3.98 kW
A -15°C / W 45°C COP 2.27 -
Power supply - 400 / 3 / 50 V / Ph / Hz
Operating temperature range - -20 ~ +40 °C
Outlet water temperature - +12 ~ +60 °C
Ele. heater Power 3.0 kW
Compressor Quantity 1 pcs
Compressor Type COPELAND EVI scroll -
Pipe - liquid Diameter 1/2 / 12 inch / mm
Pipe - gas Diameter 3/4 / 20 inch / mm
Pipe inlet / outlet Diameter DN25 (1) / DN25 (1) mm (inch)
Sound pressure level at 1 m - 41 dB(A)
Sound power level - 55.4 dB(A)
Net dimensions (w x h x d) 597 x 596 x 991 mm
Net weight - 176 kg
